MixElite Rope (8-Strand PP-PES Mix Braided)

MixElite Rope (8-Strand PP-PES Mix Braided)
MixElite Rope (8-Strand PP-PES Mix Braided)

Features and Benefits :

  • Non Floating Rope
  • Excellent shape and original weight retention
  • Excellent shock absorption capacity, Low snap-back
  •  Higher-strength and long life compared to Other ropes3
  • Loss of breaking strength in wet conditions
  • UV stabilized with medium to low elongation in use
  • Chemically inert & Better abrasion resistance
  • Less tug joining time

Product Description

         8 Strand High Tenacity Polyolefin and High Tenacity Polyester Mixed Rope are primarily used in Marine industries, Mooring applications, and Heavy lifting equipment. These ropes are produced on the latest & modern machinery using the latest technologies, hence possess excellent standards & properties. The Test certificate as per MEG 4 OCIMF guidelines may be provided.


>> Usage / Application:                   >> Technical Specification :
    • Marine industries                   • Single Point Mooring                      Material     :   Polyester & Polyolefin Mixed
    • New Shipbuilding                   • Oil Tanker operations                      Rope Construction :   8-Strand Braided
    • Rigging and sail boats           • Windlass anchor lines                      Lay Structure :   Hawser Lay
                       Specific Gravity :   1.14 g/cm3
                       Melting Point :   165 / 265 °C

>> CHARACTERISTICS:                   >> Range of Rope :
    •  Excellent shape and original weight retention                      Diameters     :  24 MM to 96 MM
    •  Excellent shock absorption capacity, Low snap-back                      Length     : 110, 220, 330, 440 Meter and up to 1300 Kg Per Coil
    •  Higher-strength and long life compared to Other ropes                      Color     : White
    •  Loss of breaking strength in wet conditions
    •  UV stabilized with medium to low elongation in use
    •  Flexible, easy to handle and splice in use
    •  Controlled elongation
    •  Chemically inert
    •  Less tug joining time
    •  Better abrasion resistance



>>   Technical Specification of MixElite Lite Rope  <<

SIZE
(Dia)

CIRC. IN
(Inch)

WEIGHT
(220 Mtr)

BREAKING STRENGTH
(Unspliced MBL)

BREAKING STRENGTH
(Eye spliced-LDBF)
28 MM 3-1/2 93.00 kg 205.00 Lbs 16000 kgf 35274 Lbs 14400  kgf 31746 Lbs
32 MM 4 122.00 kg 269.00 Lbs 20300 kgf 44753 Lbs 18270 kgf 40278 Lbs
36 MM 4-1/2 155.00 kg 341.70 Lbs 25200 kgf 55556 Lbs 22680 kgf 50000 Lbs
40 MM 5 191.00 kg 421.10 Lbs 30500 kgf 67240 Lbs 27450 kgf 60516 Lbs
44 MM 5-1/2 230.00 kg 507.10 Lbs 36300 kgf 80027 Lbs 32670 kgf 72024 Lbs
48 MM 6 274.00 kg 604.10L bs 46800 kgf 103175 Lbs 42120 kgf 92858 Lbs
52 MM 6-1/2 322.00 kg 709.90 Lbs 55100 kgf 121473 Lbs 49590 kgf 109326 Lbs
56 MM 7 374.00 kg 824.50 Lbs 63500 kgf 139992 Lbs 57150 kgf 125993 Lbs
60 MM 7-1/2 430.00 kg 948.00 Lbs 73100 kgf 161156 Lbs 65790 kgf 145041 Lbs
64 MM 8 490.00 kg 1080.30 Lbs 83500 kgf 184084 Lbs 75150 kgf 165676 Lbs
68 MM 8-1/2 553.00 kg 1219.10 Lbs 93300 kgf 205689 Lbs 83970 kgf 185120 Lbs
72 MM 9 619.00 kg 1364.60Lbs 103000 kgf 227074 Lbs 92700 kgf 204366 Lbs
80 MM 10 765.00 kg 1686.50 Lbs 127000 kgf 279984 Lbs 114300 kgf 251986 Lbs
88 MM 11 926.00 kg 2041.50 Lbs 158000 kgf 348327 Lbs 142200 kgf 313494 Lbs
96 MM 12 1103.00 kg 2431.70 Lbs 188000 kgf 414465 Lbs 169200 kgf 373018 Lbs
>> Test Method as per ISO 2307:2019
 >> Allowed Tolerance: 24mm to 96mm= +/-5%
>> Mill Certificate / DNV Certificate as Per OCIMF Guidelines Can Be Offered
